3 HP Profile Sander

Used for sanding raw wood, brush finishing metal and scaling metal.

Details:

Used for sanding raw wood, brush finishing metal and scaling metal. This profile sander has a variable speed anding head and conveyor. The brush backed sanding strips sand the raw wood. The nylon impregnated bristles help with fine raw wood sanding and act as a sanding sealer. There is also a wire brush head available for scaling metal and brush finishing metal.

Specifications:

Horsepower: 1HP or 5HP

Voltage: 230V

Phase(s): 1PH or 3PH

CFM Requirement: 550 CFM

Main Motor: 3 HP

Feed Motor: 1/4 HP

Conveyor Speed (ft/min): 8 - 25

Brush Speed (RPM): 400-1200

Conveyor Drive: AC Motor - VS Pulley

Max Thickness: 4"

Head Diameter: 11"

Width: 36"

AMPS: 17A

Weight: 800 lbs
